History of Remote Sensing: Earth Resources Technology Satellite (ERTS-1)

By the late 1960s, the first unmanned satellite specifically dedicated to multispectral remote sensing entered the planning stages. NASA carefully designed and constructed, then launched ERTS-1 (Earth Resources Technology Satellite) on July 23, 1972.

Photograph of ERTS-1.

Renamed Landsat, ERTS-1 was the first in this series (seven to date) of Earth-observing satellites that have permitted continuous coverage of most of Earth's surface since 1972. Launch dates are: Landsat 1, July 23, 1972; 2, January 22, 1975, 3, March 5, 1978; 4 , July 16, 1982, 5, March 1, 1984 (Landsat 6, launched later, failed to operate); and 7, April 15, 1999. (As of May 1999, only Landsats 5 and 7 are operational, i.e., acquiring data; the older ones have been shut down.) The first three Landsats orbited at an altitude of 570 miles (923 km); 4 and 5 at 435 miles (705 km). The orbits of all Landsats are near-polar (inclined 9.09°ree; from a longitudinal line) and Sun-synchronous (pass every time over the equator between 9:30 and 10:00 AM), making 14 passes in descending mode (southward from the North pole in the daylight mode) each day (about 103 minutes for a complete orbital circuit). After any given orbit, the spacecraft will occupy its next orbit some 1775 miles (2875 km) to the west; on the next day, the orbits are so configured so that orbit 15 has displaced westward by 98 miles (159 km) at the equator. Landsats 1-3 will reoccupy almost precisely the same orbit after 252 such orbits, or 18 days later; Landsats 4 and 5 reoccupy on a 16 day cycle. Under the above orbital conditions, and with an angular field of view if 11.58 °ree; the width of a Landsat MSS scene is 185 km (114 statute or 100 nautical miles). The continuing orbital strip is cut every 185 km to produce a given image' length. These same frame dimensions hold for the Landsat Thematic Mapper (TM) images, discussed later.

The orbits of the Landsats are termed "paths" and the location of individual images along these paths are fixed by a row system. This Worldwide Reference System is described in some detail at this U.S. Geological Survey web site.

I-19 Approximately how many square miles are enclosed are enclosed in a Landsat MSS frame? Square kilometers? Acres? (Note: there are about 640 acres in a square mile.) ANSWER

All the Landsats follow a near-polar orbit (inclined about 98 degrees to the equator; passing within 8 degrees of the poles) and are sun-synchronous, meaning the orbit precesses about Earth at the same angular rate as Earth revolves about the Sun. Thus, it crosses the equator (traveling from North to South) each day between 9:30 and 10:00 A.M., local time. Landsats 1-3 make 14 full orbits (each successive one displaced 2875 km [ 1785 miles] to the west) each day (three over the U.S.), and after 252 orbits in 18 days, they repeat their previous ground tracks. Landsats 4-5, from a lower altitude (705 km [438 miles]), cover the same ground track again every 16 days, after 233 orbits. It takes about 11,000 scenes to fully image the entire Earth's land surface (except for polar regions).

The first three Landsats used two sensor systems: the Return Beam Vidicon (RBV) and the Multi-Spectral Scanner (MSS). The RBV consisted of three TV-like cameras which used color filters to provide multispectral images in EM bands centered in the blue-green, yellow-red, and red-IR. This sensor failed early on the ERTS-1 and never came into routine use. However, a four-camera RBV on Landsat-3 was a panchromatic (0.505 - 0.750 µm) version that provided four contiguous images at 30 m (98ft) resolution; each image comprises approximately one-quarter of a full Landsat MSS scene). This RBV scene shows Cape Canaveral, Florida where the Space Shuttle launches.

RBV image of Cape Canaveral in Florida.

Landsats 4, 5 (and 6) carried, in addition to the MSS, a new instrument called the Thematic Mapper. Landsat 7 mounts only a single payload, the Enhanced Thematic Mapper (ETM+)
